The Water Screen Down is through high pressure pump and special recess walkway generator, water top-down, high-speed jet, spray formed after fan "screen", by special projector specially-made video projection screen "in", forming the water curtain movie. When the audience in watching movies, fan-shaped recess walkway and natural sky is an organic whole, when character picture, like a figure went off into the sky or leaps from heaven and drop, produce a kind of disembody and fantasy feeling, fascinating. The water curtain movie projector by mechanical device, control stents, communication mouth, software, time signal interface and DMX512 interface components. The projector engine through optical sensing control, high precision, and its control method has 3 kinds: programmable control and direct control and practical program control. The water curtain up to 20 meters, the width 30-50 meters, all sorts of VCD CD or the water curtain special films are shown on the water curtain, film effects peculiar, novel and is the best advertisement publicity tools and various plaza and rich cleans the surface of all can install the water curtain movie. Laser recess walkway projection scene grand, overpowering momentum . A dozen meters hundred meters of the water curtain in deduced the true good, which lacks creatures; Performs a wide praise space, and the vast territorial seas mountains... No matter in the park, square, playground, or in the riverside, lakesides, laser recess walkway projection will be the most attractive people focus. When the audience in watching movies, fan-shaped recess walkway and natural sky is an organic whole, when character picture, like a figure went off into the sky or leaps from heaven and drop, produce a kind of disembody and fantasy feeling, fascinating. The movie images viewed from the water curtain with that viewed from the screen in cinema. Images are clear and transparent with moving effect and more glamour, which are well received by audiences. Plus simple projection advertisement, it has certain of economic and social results, and shall be well received especially at night in summer.
Basic Requirements :
  • The water curtain movie should be set up on the place near water resource such as river, lake, manmade large scale water pond and so on
  • The water curtain movie should be played at the place outdoor at night, where no wind or less wind exists. Bing different with the film player, its projection is right aimed at the audiences
  • The water curtain generator should have high head, low flow, even spray of flow to make water in fan-shaped surface which can resist wind with Class 3 and more.
  • The projection system adopts the projector which has a variety of video sources, easy fabrication and lower cost, and can be connected with karaoke machine, live play on site and record video tape act. Via the computer
Note: as film sources are less, old and expensive, the original film player is normally not used as the projection system.
Through high-pressure water pump and special nozzle to spray water at high speed from up to down to atomize water to form fan-shaped "silver screen”, the movie is displayed on the atomized screen. When viewing movie, the fan-shaped water curtain is merged with natural night into a whole. Figures coming to or leaving the screen just like they are falling from the heaven or flying to the sky and a virtual and dreamlike feeling makes people to be charmed

Neptune Hydro Shield (Outdoor Water Screen) : Size 100 ft. × 33 ft.
A semicircle shaped wall of water, of up to 10m high and 30m wide, suitable for any kind of projection – Video / Laser / Xenon / Film etc. Easy to assemble and can be directly installed in a swimming pool or in an artificially created Water Tank/Body of a suitable size. The water fluctuation of the systems is about 1500 later/min at a pressure of 10 bars. Although the water is re-cycled, still lot of water gets wasted due to wind pressure - forcing a Mist / Spray of water. For average show duration of about 1 hour, approx. 90,000 to 120,000 liters of water is ideally required

Ideal Projection Size:
  • Video (min. 10,000 Lumens) :  40 ft. × 30 ft.
  • Laser/Xenon Images / Slides : 60 ft. × 30 ft.

The Water Curtain Movie consists of the following components:
  • Projection: SANYO PLC-XF70 ANSI Lumens 15,000 (XGA)
  • Water Pump
  • Nozzle
  • Inverter & soft starter
  • Computer & Cables
  • Sound System
  • Case Projection
  • One Effect
  • Pontoon

Components (with approx. Flight Case dimensions):
  • Submersible Water Pump : 9 ft. × 2 ft. × 2 ft.
  • Pump Motor Controller unit : 3.5 ft. × 3 ft. × 1.5 ft.
  • PVC Sheet for Water Tank : 3.5 ft. × 3 ft. × 1.5 ft.
  • Power Distribution Panel : 1.75 ft. × 1ft. × 1.25 ft.
  • Link Cables
Management of each center that mentioned above could provide earning money by marvelous capabilities of this system for environmental commercials.
